Huawei UPS5000-A-H Series User Manual

Table 2-4 Indicator status
Indicator Color Status Meaning
Mains indicator Green On The UPS is in normal mode.
O The UPS is not in normal mode.
Battery indicator Yellow On The UPS is in battery mode.
O The UPS is not in battery mode.
Blinking The battery reserve is lower than the preset
reserve warning threshold.
Bypass indicator Yellow On The UPS is in bypass mode.
O The UPS is not in bypass mode.
Fault indicator/INFO
button
Red On The UPS is faulty.
Red Blinking An alarm has been generated for the UPS.
Green On The UPS is normal.
Table 2-5 Button description
Butto
n
Function Description
ESC Back/Shutdown On any screen except the default screen, press ESC to return to the
upper-level menu. (The upper-level screen for the main menu list
is the default screen.)
On the default screen, press ESC for more than 5s, release the
button when you hear a beep sound, and press on the
displayed shutdown screen to shut down the inverter.
▲ Up Press ▲ or ▼ to scroll upward or downward.
You can set a value by using the list or step increase or decrease.
▼ Down
Startup/Enter/Mute
On the default screen, hold down for more than 5s, release
the button when you hear a beep sound, and press on the
displayed startup screen to start the UPS.
On the default screen, press to access the main menu.
On any menu screen, press to access the lower-level menu. If
the menu is the last level, an information screen is displayed.
When the buzzer buzzes, hold down the button for more than 2s
and then release the button to mute the buzzer. The sound
generated due to low battery reserve cannot be muted by this
button.
UPS5000-A-(30 kVA-120 kVA)
User Manual 2 Product Overview
Issue 17 (2024-02-21) Copyright © Huawei Digital Power Technologies Co., Ltd. 48
