134
Man Overboard Navigation
MAN OVERBOARD (MOB) NAVIGATION
A
s soon as you know that you have a man overboard (MOB), activate Man Overboard navigation to maximize the chances for a
s
uccessful rescue. Man Overboard navigation marks the approximate point where the person went overboard and starts continuous
n
avigation toward the Man Overboard waypoint.
Activate Man Overboard Navigation
1. Press and hold the GOTO/MOB key until Man Overboard Navigation is activated.
Press and hold to start
MOB navigation
Activating Man Overboard Navigation
Man
Overboard
marked
Elapsed time since the MOB
waypoint was marked
Man Overboard
waypoint position
Man Overboard
navigation in progress
