184
AutoChart Live
3. STOP RECORDING
U
se the instructions in this section to stop recording. Your map is automatically saved to the control head (internal) or to the
Z
eroLine Map Card if it is installed.
1. Chart X-Press Menu: With a Chart View displayed on-screen, press the MENU key once.
2. Select AutoChart Live. Press the RIGHT Cursor key.
3. Select Record.
4. Select Off.
CORRECT DATA
If you see an irregularity in the data (such as lost depth), it can be deleted. Recording must be turned off while you correct the data.
1. Chart X-Press Menu: With a Chart View displayed on-screen, press the MENU key once.
2. Select AutoChart Live. Press the RIGHT Cursor key.
3. Select Show Raw Data. Press the RIGHT Cursor key.
4. Press the +ZOOM key to see individual data points.
5. Move the cursor over a data point.
6. From the AutoChart Live menu, select Delete. Press the RIGHT Cursor key.
If you do not have a ZeroLine Map Card installed, and the control head storage (8 hours) is reached, the control head
will provide a dialog box to Confirm or Clear Data. To save your map and turn off recording, select Confirm. To erase
your map and start over, select Clear Data.
Selecting a Data Point
cursor selecting
a data point
