68
Circular Flasher
DISPLAY THE CIRCULAR FLASHER VIEW ON-SCREEN
C
ircular Flasher View provides two ways to view sonar data in traditional flasher format. The view is controlled by the Ice Fishing Mode
m
enu in the Sonar tab.
Display the Circular Flasher View
1. Press and hold the VIEW key.
2. Select Sonar > Circular Flasher View.
Turn on Ice Fishing Mode
1. Main Menu: Press the MENU key twice. Select the Sonar tab.
2. Select Ice Fishing Mode.
3. Select On.
Select the Digital Depth Source (HELIX DI G2, HELIX CHIRP DI GPS G2 only)
If you connect an ice transducer to the HELIX DI G2 or HELIX CHIRP DI GPS G2 control head, set the Digital Depth Source to 2D
Element. See Set up Sonar for details.
1. Main Menu (Advanced User Mode): Press the MENU key twice. Select the Sonar tab.
2. Select Digital Depth Source.
3. Select 2D Element.
Circular Flasher View with
Ice Fishing Mode Turned On
On
When Ice Fishing Mode is on, the Circular Flasher View displays Real Time Sonar (RTS) returns
in traditional flasher format with additional features, including Depth Cursor and Zoom.
Off
When Ice Fishing Mode is off, the Circular Flasher View displays Real Time Sonar (RTS) returns
in traditional flasher format.
