Humminbird HELIX 7 G2 SERIES User Manual

7
Introduction
INTRODUCTION
T
he instructions in this manual describe the HELIX G2 Series control head operations. Review the following table to understand the
f
eatures that apply to your control head.
Accessories: For the latest list of accessories that are compatible with your control head, visit our Web site at humminbird.com.
Register and Update: It is important to register your products and keep your software up to date. Visit our Web site at
humminbird.com to set up an account, update control head and accessory software, and purchase additional equipment. Also, see
Update Software in this manual for more information.
Model
2D
Sonar
Down
Imaging
Side
Imaging
CHIRP
GPS
(Charts and Navigation)
HELIX GPS G2
HELIX SONAR G2
External GPS, trackplotting
(separate purchase required)
HELIX DI G2
External GPS, trackplotting
(separate purchase required)
HELIX CHIRP DI G2
External GPS, trackplotting
(separate purchase required)
HELIX CHIRP GPS G2
HELIX CHIRP DI GPS G2
HELIX CHIRP SI GPS G2

Humminbird HELIX 7 G2 SERIES Specifications

General

Power Input	10-20 VDC
Operating Temperature	-15°C to 55°C
Water Rating	IPX7
GPS Chartplotting	Yes
Display Size	7 inches
Resolution	800 x 480 pixels
Sonar	Yes
Sonar Frequencies Supported	83 kHz, 200 kHz
Max Depth	1500 ft
Power Output	500 W RMS
GPS	Internal GPS
Memory Card Slot	microSD
Connectivity	Ethernet
