Humminbird HELIX 7 G2 SERIES User Manual

10
GETTING STARTED
The procedures in this section describe how to get started with your control head. Some of the settings in this section are a one-
t
ime set up, and other settings (such as checking the GPS reception) you will use each time you hit the water.
Power On
Follow the instructions below to power on your Humminbird control head.
1. Press the POWER key.
2. When the Title screen is displayed, press the MENU key.
Title Screen
Press the MENU key
Getting Started

Humminbird HELIX 7 G2 SERIES Specifications

General

Power Input	10-20 VDC
Operating Temperature	-15°C to 55°C
Water Rating	IPX7
GPS Chartplotting	Yes
Display Size	7 inches
Resolution	800 x 480 pixels
Sonar	Yes
Sonar Frequencies Supported	83 kHz, 200 kHz
Max Depth	1500 ft
Power Output	500 W RMS
GPS	Internal GPS
Memory Card Slot	microSD
Connectivity	Ethernet
