Humminbird HELIX 7 G2 SERIES User Manual

5
AutoChart Live Overview 178
Plan Your Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .178
Prepare the Control Head for Mapping . . . . . . . . . . . . . . . . . . . .179
R
ecord your Custom Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .182
Stop Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .184
Correct Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .184
Display/Hide your Custom Map . . . . . . . . . . . . . . . . . . . . . . . . . .185
Adjust the Map Display Settings . . . . . . . . . . . . . . . . . . . . . . . . .186
Manage your Control Head 190
Update Software 195
Maintenance 196
Troubleshooting 197
Specifications 199
Contact Humminbird 215
TABLE OF CONTENTS

Humminbird HELIX 7 G2 SERIES Specifications

General

Power Input	10-20 VDC
Operating Temperature	-15°C to 55°C
Water Rating	IPX7
GPS Chartplotting	Yes
Display Size	7 inches
Resolution	800 x 480 pixels
Sonar	Yes
Sonar Frequencies Supported	83 kHz, 200 kHz
Max Depth	1500 ft
Power Output	500 W RMS
GPS	Internal GPS
Memory Card Slot	microSD
Connectivity	Ethernet
