Stage x Active (Cooling) All zones assigned to stage x are cooling to the stage setpoint.
Stage x Soaking
(Cooling)
After cooling down, the system will maintain the stage x setpoint until
the soak timer expires.
Stage 4 Running
Indefinitely
The system will remain in stage 4 until the user presses the Start button
to heat the zones to the normal setpoint.
Bake Out Check The system is searching for any bake out conditions. These bake out
conditions would be less severe than a earth leakage.
Earth Leakage Check The system is searching for any earth leakage conditions.
Circuit Test The system is verifying that there are no heater circuit faults (open circuit,
short circuit, leakage or wrong heater) on any zones.
System Modes Table (Continued)
System Mode Description
