8-37: Machine Assemblies and Parts Lists
Boxxer 318 on 85 RMT w/ 50 URT Assembly Parts List
1 - - - Assembly, 85 Gallon Rotomolded Tank 1
2 - - - Assembly, Machine 1
3 000-033-058 Clamp, Ø2.5” Mufer 1
4 000-001-107 Adapter, Silencer Exhaust 1
5 - - - Assembly, 50 Gallon URT for 85 RMT 1
6 000-068-776 Hose, Ø2.50” I.D. x 30” Lg. Flexible Wire Reinforced 1
7 000-143-150 Screw, 3/8”-16UNC x 4” Lg. Hex Head (Full Thread) 6
Item Part Number Description Qty Item Part Number Description Qty
8 000-174-005 Washer, 3/8” Flat 6
9 000-174-021 Washer, 3/8” Lock 6
10 000-068-042 Hose, Ø2” Vacuum - Black 1
11 000-068-135 Hose, Ø1.5” Red Stripe Type 55 - Bulk 1
12 000-052-169 Cuff, Ø2” Vacuum Hose 2
13 - - - Assembly, Dump and Vacuum Bracket 1
14 - - - Assembly, APO Connection Kit 1
