HydraMaster Boxxer 318 - Hi-PSI Manifold Assembly Parts List

Machine Assemblies and Parts Lists: 8-22
Hi-PSI Manifold Assembly Parts List
1 000-049-016 Filter, 1/4” NPT Replacement “Y” 2
2 000-155-020 Spring, 0.540 O.D. x 0.041 Wire x 1.00 Lg. 2
3 000-180-004 Orice, Set Screw 0.033” 1
4 000-180-006 Orice, Set Screw 0.061” 1
5 000-149-540 Sensor, RTD Compression Fitting Style 1
6 000-052-587 Compression, 3/16” x 1/4” NPT Thermocouple 1
7 000-106-007 Plug, 1/4” NPT Allen Head 1
Item Part Number Description Qty Item Part Number Description Qty
8 000-090-010 Manifold, Hi PSI 1
9 000-106-111 Plug, 1/2” NPT Allen Head 2
10 000-149-027 Sensor, 285°F Nason - 3/8” NPT 1
11 000-052-023 Tee, 3/8” NPT Male Street 1
12 000-052-527 Nipple, 1/4” SAE x 1/4” NPT 2
13 000-052-423 Bushing, Modied Set Screw Orice 2
14 000-052-528 Nipple, 3/8” M JIC x 3/8” NPT 1
