8-39: Machine Assemblies and Parts Lists
50 Gallon URT for 85 RMT Assembly Parts List
1 000-094-063 Nut, #6-32UNC Nylock S/S 8
2 000-086-008 Latch, Bungee - Catch 2
3 000-052-222 Elbow, 2” Barb x 2” FPT 1
4 000-041-459 Cover, Recovery Tank - Weldment 1
5 000-143-165 Screw, #6-32UNC x 3/8” Lg. Button Head 8
6 000-049-153 Filter, Flat - Universal Recovery Tank 1
7 000-131-021 Trimlok, 5/8” x 1/8” 1
8 000-086-008 Latch, Bungee - Strike 2
9 000-057-206 Gasket, Adapter - URT 2
10 - - - Assembly, Vacuum Relief Valve - URT 1
11 000-174-003 Washer, 1/4” Flat 20
12 000-143-002 Screw, 1/4”-20UNC x 1.00” Lg. Hex Head 16
13 000-159-132 Tank, 50 Gallon Universal Recovery 1
14 000-094-113 Nut, 1/4”-20UNC Neoprene Wellnut 4
15 000-057-216 Gasket, Ø2.200” I.D. x Ø2.875” O.D. 1
16 000-001-153 Adapter, 1-1/2” FPT x 4 Bolt Flange 1
17 000-174-060 Washer, 1/4” Rubber Backed 8
18 000-052-316 Adapter, 1-1/2” NPT x 1-1/2” M Slip 1
19 000-052-246 Elbow, 1-1/2” F Slip x F Slip Sweep 1
20 000-052-226 Insert, 1-1/2” NPT x 1-1/2” Barb (Grey) 1
21 000-052-243 Adapter, 1-1/2” FPT x 1-1/2” M Slip 1
22 000-106-019 Plug, 1-1/2” NPT 1
Item Part Number Description Qty Item Part Number Description Qty
23 - - - Assembly, Dura-Flow APO 90° 1
24 000-052-102 Insert, #46 (1/4” NPT x 3/8” Barb) 1
25 000-052-085 Elbow, 1/4” NPT Street 1
26 000-081-039 Label, Maintenance and Lube Schedule 1
27 000-131-021 Trimlok, 5/8” x 1/8” 1
28 000-049-155 Basket, Filter - Small 1
29 000-052-219 Adapter, 2” NPT x 2” F Slip 1
30 000-057-015 Gasket, 1-1/2” Bulkhead Fitting 1
31 000-052-071 Nipple, 1/4” NPT Hex 1
32 000-012-002 Block, 6 Post Terminal 1
33 000-143-051 Screw, #8-32UNC x 3/4” Lg. Binder Head 2
34 000-052-088 Elbow, 1/4” FPT x FPT 1
35 000-052-090 Tee, 1/4” NPT Branch M-F-F 1
36 000-052-073 Nipple, 3/8” NPT x 1/4” NPT Hex 1
37 000-169-082 Valve, 12 Volt Solenoid 1200 PSI 1
38 000-052-662 Nipple, 3/8” NPT x 1/4” M SAE 1
39 000-157-090 Float, Lever Switch 2
40 000-094-059 Nut, #8-32UNC Nylock 2
41 000-094-009 Nut, 1/4”-20UNC Nylock 12
42 000-001-134 Adapter, Tank To Ø2.5” x 90° Blower Hose 1
43 000-057-175 Gasket, Harwil Float 1
44 000-052-750 Fitting, Bulkhead - Harwil Float 1
