HydraMaster Boxxer 318 - Figure 8-2. Machine Assembly - Front Right View

8-3: Machine Assemblies and Parts Lists
DRAWN
7087
- - -
D
C
B
A
A
B
C
D
1
2
3
45
6
7
8
8
7
6
5
4
3
2
1
E
F
BOXXER 318
ANGULAR= 1°
BREAK ALL SHARP EDGES 0.005-.015
FINISH
125
-
REV
APPVD
SCALE: 1:3
SHEET 1 OF 2
E
F
MACHINE
Mukilteo, Washington 98275
DRAWING NUMBER
- - -
7010
B.R.T.
D
SIZE
PROPRIETARY INFORMATION
11015 47th Avenue West,
.XXX= .010
DIMENSIONS ARE IN INCHES
PART NUMBER
CODE:
NEXT ASSY
B.R.T.
APPLICATION
L.O.L.CHECKED
SEE NOTES
1/18/2007
ASSEMBLY, MACHINE
USED ON
1/18/2007
1/18/2007
TOLERANCES
.X= .1
.XX= .03
UNLESS OTHERWISE NOTED
- - -
7345
2 3 4 5 3 5 61 5 3
NOTES:
1. REFERENCE BOM'S:
610-050-061 ASSEMBLY, MACHINE CONSOLE
610-001-001 ASSEMBLY, FRAME
610-002-001 ASSEMBLY, BLOWER
610-004-001 ASSEMBLY, ENGINE
610-006-001 ASSEMBLY, HEAT EXCHANGER
610-007-001 ASSEMBLY, PUMP
610-008-001 ASSEMBLY, HI PSI MANIFOLD
610-009-001 ASSEMBLY, BYPASS VALVE MANIFOLD
610-011-001 ASSEMBLY, ELECTRICAL PANEL
610-012-001 ASSEMBLY, WATER BOX
610-013-001 ASSEMBLY, EXHAUST
610-018-001 ASSEMBLY, DASH
2. ITEMS 1 ISE PART OF 610-001-001.
REVISIONS
LTR REVISION CODE DATE BY CHKD APPVD
ITEM NO. QTY. DESCRIPTION MATERIAL PART NO. DWG. NO.
7 1 COVER, SIDE - 17.250" X 14.316" ASTM A366 000-041-452 7023
6 1 COVER, TOP - MACHINE 5052-H32 000-041-453 7024
5 13 WASHER, #10 FLAT S.STEEL 000-174-001 - - -
4 9 WASHER, #10 LOCK S.STEEL 000-174-014 - - -
3 13 SCREW, #10-24UNC X 0.50" LG HEX HEAD S. STEEL 000-143-126 - - -
2 1 COVER, SIDE - 19.900" x 14.316" ASTM A366 000-041-451 7022
1 1 ASSEMBLY, FRAME VARIOUS SEE NOTES 7011
Machine Assembly - Front Right ViewFigure 8-2.
7010
