Machine Assemblies and Parts Lists: 8-20
Dash Assembly Parts List
1 - - - Chemical Metering Valve - Knob Only 1
2 - - - Knob, 3-Way Ball Valve (Part Of 000-169-0171) 1
3 000-001-148 Adapter, 2.5" Exhaust Turndown 1
4 000-025-003 Cable, Choke With Detent 1
5 000-025-020 Cable, Throttle Locking 1
6 000-052-051 Quick Connect, 440 Female w/ EPDM O-Ring 1
7 000-052-052 Quick Connect, 660 3/8" Brass w/ EPDM O-Ring 1
8 000-052-069 Nipple, 1/8" NPT Hex 1
9 000-052-073 Nipple, 3/8" NPT X 1/4" NPT Hex 1
10 000-052-084 Elbow, 1/8" NPT Street 1
11 000-052-088 Elbow, 1/4" FPT X FPT 1
12 000-052-090 Tee, 1/4" NPT Branch M-F-F 1
13 000-052-096 Insert, #F23 (1/8" FPT X 3/16" Barb) 1
14 000-052-099 Insert, #26 (1/8" NPT X 3/8" Barb) 3
15 000-052-104 Insert, #66 (3/8" NPT X 3/8" Barb) 1
16 000-052-105 Insert, #68 (3/8" NPT X 1/2" Barb) 2
17 000-052-272 Cup, Gravity Feed Oil Blower Lube Port 1
18 000-052-527 Nipple, 1/4" SAE X 1/4" NPT 1
19 000-052-528 Nipple, 3/8" M Jic X 3/8" NPT 1
20 000-052-530 Nipple, 1/4" SAE X 1/8" NPT 1
21 000-052-531 Elbow, 1/8" NPT X 1/4" SAE 1
22 000-052-532 Elbow, 1/4" SAE X 1/4" NPT 1
23 000-061-056 Knob, Temperature Adjustment 1
24 000-074-007 Gauge, Pressure 0 -1,500 psi 1
25 000-074-017 Gauge, 30" Hg. Vacuum - HydraMaster 1
26 000-074-030 Meter, Chemical Flow Raw 1
27 000-074-170 Meter, Rectangular Hour w/O Bezel 1
28 000-094-009 Nut, 1/4"-20UNC Nylock 4
29 000-094-070 Nut, 5mm Nylock 4
30 000-094-092 Nut, 7/16"-20UNF Hex Jam 2
31 000-094-098 Nut, 7/16"-24UNF - 2 Way Metering Valve 1
32 000-100-169 Panel, Dash 1
33 000-100-170 Panel, Grill 1
34 000-131-131 Trimlok, 3/8" X 1/8" Rubber 1
35 000-135-052 Regulator, Hi PSI Snubber 1
36 000-143-126 Screw, #10-24UNC X 0.50" Lg. Hex Head 2
37 000-143-166 Screw, #10-24UNC X 3/8" Lg. Hex Head 2
38 000-143-171 Screw, #10-24UNC X 1.25" Hex Head 4
39 000-143-542 Screw, 1/4"-28UNF X 0.50" Lg. Hex Head 2
40 000-149-560 Thermostat, Potentiometer (see note on page 8-19) 1
41 000-155-053 Spring, 1/4" Belleville Washer 2
42 000-157-017 Switch, Ignition - B & S 1
43 000-157-040 Switch, 20 Amp Rocker 2
44 000-169-0171 Valve, 3-Way Ball O-Ring Style 1
45 000-169-064 Valve, 3/8" NPT Full Port Ball 1
46 000-169-160 Valve, Chemical Metering 1
47 000-169-219 Valve, Check 80 psi - Last Step Chemical 1
48 000-174-001 Washer, #10 S/S Flat 8
49 000-174-003 Washer, 1/4" Flat 4
50 000-174-007 Washer, 1/2" Flat 3
51 000-174-008 Washer, 5/8" Flat 4
52 000-174-014 Washer, #10 Lock 2
53 000-174-022 Washer, 7/16" Lock 1
54 000-174-030 Washer, 5/8" I.D. X 7/8" O.D.X 0.010" Thk 1
55 000-174-032 Washer, 3/8" Flat 2
56 000-174-038 Washer, 7/16" SAE Flat 1
57 000-174-058 Washer, 21/32" I.D. X 27/32" O.D. Nylon 1
58 000-174-062 Washer,1/2" I.D. X 3/4" O.D. X 0.010" Thk 1
59 - - - Assembly, Hi PSI Manifold 1
60 - - - Assembly, By-pass Valve 1
61 - - - Label, Left Dash 1
62 - - - Label, Right Dash 1
63 - - - Label, Temperature 1
64 - - - Label, Dash Warning 1
Item Part Number Description Qty Item Part Number Description Qty
