Machine Assemblies and Parts Lists: 8-4
Machine Assembly Parts List
1 - - - Assembly, Frame 1
2 000-041-451 Cover, Side - 19.900” x 14.316” 1
3 000-143-126 Screw, #10-24UNC x 0.50” Lg. Hex Head 13
4 000-174-014 Washer, #10 Lock 9
Item Part Number Description Qty
5 000-174-001 Washer, #10 Flat 13
6 000-041-011 Cover, Top - Machine 1
7 000-041-452 Cover, Side - 17.250” x 14.316” 1
Item Part Number Description Qty
