HydraMaster Boxxer 318 - Blower Assembly Parts List; Figure 8-7. Blower Assembly

8-11: Machine Assemblies and Parts Lists
Blower AssemblyFigure 8-7.
7014
7
8
2
4
3
6
5
4
5
1
9
NOTE:
1. REFERENCE BOM P/N 610-002-001.
B.R.T.
- - -
BOXXER 318
- - -- - -
D
C
B
A
B
C
D
123
45
6
7
8
8 7 6 5
4
3 2
1
E
F
E
F
A
ASSEMBLY, BLOWER
-
REV
7014SEE NOTES
01/11/2008
01/11/2008
01/11/2008
USED ON
L.O.L.
APPVD
CHECKED
NEXT ASSY
B.R.T.
FINISH
11015 47th Avenue West,
DRAWN
125
DIMENSIONS ARE IN INCHES
APPLICATION CODE:
PART NUMBER
UNLESS OTHERWISE NOTED
.XXX= .010
Mukilteo, Washington 98275
PROPRIETARY INFORMATION
DRAWING NUMBER
SHEET 1 OF 1
SCALE: 1:2
BREAK ALL SHARP EDGES 0.005-.015
ANGULAR= 1°
SIZE
C
TOLERANCES
.X= .1
.XX= .03
MACHINE
7011
APPVDCHKDBYDATECODEREVISIONLTR
REVISIONS
ITEM NO. QTY. DESCRIPTION MATERIAL PART NO. DWG. NO.
9 4 SCREW, 3/8-16UNC x 1" HEX HEAD - GRADE 8 STEEL 000-143-018 - - -
8 4 WASHER, 5/16" FLAT STEEL 000-174-004 - - -
7 4 WASHER, BLOWER FEET STEEL 000-174-068 4763
6 1 ADAPTER, 2.5" NPT TO 2.5" OD TUBE STEEL 000-001-140 7050
5 2 HOSE, DRAIN VARIOUS 000-068-219 - - -
4 4 ELBOW, 3/8" BRASS x 45° STREET BRASS 000-052-083 - - -
3 1 BLOWER, 3006 COMPETITOR SL STEEL 000-111-134 - - -
2 1 ADAPTER, 2.5" NPT X 2.5" OD TUBE - ELBOW STEEL 000-001-141 7048
1 2 INSERT,1/8 NPT x 5/32 BARB -ELBOW BRASS 000-052-106 - - -
Blower Assembly Parts List
1 000-052-106 Insert, 1/8” NPT X 5/32” Barb X 90° 2
2 000-001-141 Adapter, 2.5” NPT X 2.5” O.D.Tube - Elbow 1
3 000-111-134 Blower, 3006 Competitor 1
4 000-052-083 Elbow, 3/8” NPT Street X 45° 4
5 000-068-219 Hose, Drain 2
6 000-001-140 Adapter, 2.5” NPT To 2.5” O.D.Tube 1
7 000-174-068 Washer, Blower Feet 4
8 000-174-004 Washer, 5/16” Flat 4
9 000-143-018 Screw, 3/8-16UNC X 1” Hex Head - Grade 8 4
Item Part Number Description Qty
