HydraMaster Boxxer 318 - Figure 8-15. Hi-PSI Manifold Assembly

8-21: Machine Assemblies and Parts Lists
Hi-PSI Manifold AssemblyFigure 8-15.
7019 Rev. A
8
7
5 6
3 4
1
2
9
14 12
11
9
10
13
NOTES:
1. REFERENCE BOM P/N 610-008-001.
A
A
REVISIONS
LTR REVISION CODE DATE BY CHKD APPVD
A
CHANGED EXPLODED VIEW TO
ORIENT ITEMS 12 & 13 CORRECTLY.
LRIP 1/17/2008 BRT LOL BRT
14 1 NIPPLE, 3/8" M JIC x 3/8" NPT BRASS 000-052-528 - - -
13 2 BUSHING, MODIFIED SET SCREW ORIFICE BRASS 000-052-423 2768
12 2 NIPPLE, 1/4" SAE x 1/4" NPT BRASS 000-052-527 - - -
11 1 TEE, 3/8" NPT MALE STREET BRASS 000-052-023 - - -
10 1 SENSOR, 285F NASON- 3/8" NPT VARIOUS 000-149-027 - - -
9 2 PLUG, 1/2" NPT ALLEN HEAD BRASS 000-106-111
8 1 MANIFOLD, HI PSI BRASS 000-090-010 4554
7 1 PLUG, 1/4" NPT ALLEN HEAD BRASS 000-106-007 - - -
6 1 COMPRESSION, 3/16" x 1/4" NPT THERMOCOUPLE BRASS 000-052-587 - - -
5 1 SENSOR, RTD COMPRESSION FITTING STYLE VARIOUS 000-149-540 - - -
4 1 ORIFICE, SET SCREW 0.061" S. STEEL 000-180-006 4286
3 1 ORIFICE, SET SCREW 0.033" S. STEEL 000-180-004 3679
2 2 SPRING, 0.540 O.D. x 0.041 WIRE x 1.00 LG. S.STEEL 000-155-020 -
1 2 FILTER, 1/4" NPT REPLACEMENT "Y" VARIOUS 000-049-016 -
ITEM NO. QTY. DESCRIPTION MATERIAL PART NO. DWG. NO.
D
C
B
A
B
C
D
1 2 3
4 5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
A
ASSEMBLY, HI PSI MANIFOLD
A
REV
7019 SEE NOTES
01/14/2008
01/14/2008
01/14/2008
USED ON NEXT ASSY
APPLICATION CODE:
PART NUMBER
UNLESS OTHERWISE NOTED
DIMENSIONS ARE IN INCHES
BREAK ALL SHARP EDGES 0.005-.015
TOLERANCES
.X= .1
.XX= .03
.XXX= .010
ANGULAR= 1°
SIZE
C
11015 47th Avenue West,
Mukilteo, Washington 98275
PROPRIETARY INFORMATION
DRAWING NUMBER
SHEET 1 OF 1
SCALE: 1:1
APPVD
CHECKED
DRAWN
125
MACHINE
FINISH
B.R.T
L.O.L.
B.R.T.
- - -
BOXXER 318
- - -- - -
7018
