HydraMaster Boxxer 318 - Frame Assembly Parts List

Machine Assemblies and Parts Lists: 8-8
Frame Assembly Parts List
1 - - - Assembly, Heat Exchanger 1
2 - - - Assembly, Engine 1
3 - - - Assembly, Blower 1
4 - - - Assembly, Water Box 1
5 - - - Assembly, Pump 1
6 - - - Assembly, Dash 1
7 - - - Assembly, Electrical Panel 1
8 - - - Assembly, Silencer 1
9 - - - Assembly, Exhaust 1
10 - - - Assembly, Idler Pulley 1
11 000-010-124 Belt, #9430hd 1
12 000-027-110 Cap, 2” X 3” Frame End 2
13 000-033-012 Clamp, Size #44 Hose 2
14 000-033-050 Clamp, 1-3/4” Cushion Loop 1
15 000-033-052 Clamp, 1-1/4” S/S EDPM 2
16 000-033-057 Clamp, 1” Cushion Loop 2
17 000-033-067 Clamp, 2” Cushion Loop 2
18 000-055-188 Frame Weldment- Boxxer 318 1
19 000-068-122 Hose, Ø 2.5” I.D. Silicone X 14.5” Lg. 1
20 000-105-012 Plate, Machine Serial I.D. 1
21 000-131-131 Trimlok, 3/8” X 1/8” Rubber 1
22 000-140-001 Rivet, Ab4-3a Aluminum Pop (1/8” X 1/4”) 2
23 000-143-114 Screw, #10-24UNC X 0.50” Lg. Flat Head Phillips 4
24 000-143-126 Screw, #10-24UNC X 0.50” Lg. Hex Head 13
25 000-154-156 Spacer, Machine Rising 4” X 35” 2
26 000-174-001 Washer, #10 S/S Flat 13
Item Part Number Description Qty Item Part Number Description Qty
