Machine Assemblies and Parts Lists: 8-10
Engine Assembly Parts List
1 000-020-025 Bushing, H X 1” 1
2 000-033-046 Clamp, 1/2 Wide X 1/2 Tube 1
3 000-033-117 Clamp, 1” Cushion Loop w/ 7/16 Mount Hole 1
4 000-039-054 Coupler, 40 Series 1
5 000-047-028 Engine, B&S 18hp 1
6 000-068-219 Hose, Drain 1
7 000-068-660 Hose, 1/4” Fuel 1
8 000-077-010 Key, 1/4” X 1-1/2” Lg. 2
9 000-109-040 Pulley, Ak47-H 1
10 000-143-375 Screw, 5/16”-18UNC X 1.75” Lg. Hex Head Grd. 8 Z/P 4
11 000-174-049 Washer, 5/16” Flat 4
Item Part Number Description Qty Item Part Number Description Qty
