A
B
B
REVISIONS
LTR REVISION CODE DATE BY CHKD APPVD
A
ITEM 25 WAS QTY. 4; DEL ITEM 26 (143-539);
RELOCATED ITEMS 10,11,13 & 36; ADDED
NOTE 3.
LRIP 01/16/2008 L.O.L. B.R.T. B.R.T.
B
ITEM 20 WAS MISSING INFO. IN BOM;
ADDED NOTE 4; RENUMBERED BOM.
LRIP 2/19/2008 L.O.L. B.R.T. B.R.T.
ITEM NO. QTY. DESCRIPTION MATERIAL PART NO. DWG. NO.
35 1 FLOAT, LEVER SWITCH VARIOUS 000-157-090 - - -
34 2 SCREW, #8-32UNC x 3/4" LG.BINDER HEAD S. STEEL 000-143-051 - - -
33 1 BLOCK, 6 POST TERMINAL VARIOUS 000-012-002 - - -
32 1 ELBOW, 2" BARB x 2" FPT ABS 000-052-222 - - -
31 1 GASKET, 1-1/2" BULKHEAD FITTING VARIOUS 000-057-015 - - -
30 1 ADAPTER, 2" NPT x 2" F SLIP ABS 000-052-219 - - -
29 1 BASKET, FILTER - SMALL VARIOUS 000-049-155 - - -
28 1 TRIMLOK, 5/8" x 1/8" RUBBER 000-131-021 - - -
27 1 LABEL, MAINTENANCE & LUBE SCHEDULE
3M 200 MP
ADHESIVE
SEE NOTES 6561
26 1 NIPPLE, 1/4" NPT HEX BRASS 000-052-071 - - -
25 1 ELBOW, 1/4" FPT x FPT BRASS 000-052-088 - - -
24 1 TEE, 1/4" NPT BRANCH M-F-F BRASS 000-052-090 - - -
23 1 ELBOW, 1/4" NPT STREET BRASS 000-052-085 - - -
22 1 INSERT, #46 (1/4" NPT x 3/8" BARB) BRASS 000-052-102 - - -
21 1 NIPPLE, 3/8" NPT x 1/4" NPT HEX BRASS 000-052-073 - - -
20 1 VALVE, 12 VOLT SOLENOID 1200 PSI BRASS 000-169-082 - - -
19 1 NIPPLE, 3/8" NPT x 1/4" M SAE BRASS 000-052-662 - - -
18 1 NIPPLE, 1-1/2" IPS CLOSE s/s S. STEEL 000-052-763 - - -
17 1 VALVE, 1-1/2" FULL PORT BALL BRASS 000-169-022 - - -
16 1 INSERT,1-1/2" NPT x 1-1/2" BARB (GREY) PVC 000-052-226 - - -
15 1 TANK, 50 GALLON UNIVERSAL RECOVERY ALUMINUM 000-159-132 7231
14 1 ADAPTER, TANK TO Ø2.5" x 90° BLOWER HOSE STEEL 000-001-134 6887
13 8 NUT,1/4"-20UNC NYLOCK VARIOUS 000-094-009 - - -
12 1 ASSEMBLY, VACUUM RELIEF VALVE - URT VARIOUS SEE NOTES 6894
11 8 SCREW, 1/4"-20UNC x 1.00" LG. HEX HEAD S. STEEL 000-143-002 - - -
10 16 WASHER, 1/4" FLAT S. STEEL 000-174-003 - - -
9 2 GASKET, ADPATER - URT RUBBER 000-057-206 6897
8 2 LATCH, BUNGIE - STRIKE VARIOUS 000-086-008 - - -
7 1 TRIMLOK, 5/8" x 1/8" RUBBER 000-131-021 - - -
6 2 NUT, #8-32UNC NYLOCK S. STEEL 000-094-059 - - -
5 1 FILTER, FLAT - UNIVERSAL RECOVERY TANK VARIOUS 000-049-153 6851
4 8 NUT, #6-32UNC NYLOCK s/s S. STEEL 000-094-063 - - -
3 2 LATCH, BUNGIE - CATCH STEEL 000-086-008 - - -
2 8 SCREW, #6-32UNC x 3/8" LG. BUTTON HEAD STEEL 000-143-165 - - -
1 1 COVER, RECOVERY TANK - WELDMENT ALUMINUM 000-041-459 7241
NOTES:
1. REFERENCE BOM P/N 610-003-001.
2. ITEM 12 IS PART OF P/N 610-003-001.
3. ITEM 27 IS PART OF LABEL SET P/N 000-081-039.
4. ITEMS 16-18 ARE PART OF P/N 000-078-052.
32
3
31
30
1
2
29
25
26
28
24
21
22
34
6
5
33
19
35
14
7
11
17
16
2
18
12
9
8
9
8
3
11
10
10
4
15
2
4
HIDDEN
HIDDEN
HIDDEN
HIDDEN
HIDDEN
10
27
13
23
20
4
- - -
- - -
D
C
B
A
A
B
C
D
1
2
3
45
6
7
8
8
7
6
5
4
3
2
1
E
F
E
BOXXER 318
BREAK ALL SHARP EDGES 0.005-.015
FINISH
125
DRAWN
CHECKED
APPVD
SCALE: 1:3
SHEET 1 OF 1
DRAWING NUMBER
F
MACHINE
Mukilteo, Washington 98275
D
PROPRIETARY INFORMATION
- - -
B.R.T.
B
SIZE
ANGULAR= 1°
11015 47th Avenue West,
.XXX= .010
DIMENSIONS ARE IN INCHES
PART NUMBER
CODE:
APPLICATION
NEXT ASSY USED ON
L.O.L.
B.R.T.
01/08/2008
01/08/2008
01/08/2008
SEE NOTES
REV
ASSEMBLY, 50 GALLON URT
7230
TOLERANCES
.X= .1
.XX= .03
UNLESS OTHERWISE NOTED
- - -
