218 ArcGlide THC Instruction Manual 806450
4 – Maintenance
21 Hold output B 22 Start output A
23 Start output B 24 Spare output A
25 Spare output B 26 Remote on output A
27 Remote on output B 28 Common
29 Common 30 Common
31 +24 VDC output 32 +24 VDC output
33 +24 VDC output 34 1/50 Arc voltage +
35 1/50 Arc voltage - 36 Not connected
37 Not connected
J6 CNC interface
Pin No. Signal Pin No. Signal
1 Cycle Start input + 2 Cycle Start input -
3 Low gain input + 4 Low gain input -
5 AVC Disable input + 6 AVC Disable input -
7 IHS Sync input + 8 IHS Sync input -
9 Spare input 1 + (Do not use) 10 Spare input 1 - (Do not use)
11 Spare input 2 + (Do not use) 12 Spare input 2 - (Do not use)
13 IHS Complete output A 14 IHS Complete output B
15 Retract complete output A 16 Retract complete output B
17 Machine Motion output A 18 Machine Motion output B
19 THC Error output A 20 THC Error output B
21 Torch Breakaway output A 22 Torch Breakaway output B
23 CNC spare output A 24 CNC spare output B
25 Interlock input + 26 Interlock input -
27 Interlock output A 28 Interlock output B
29 Common 30 Common
31 Common 32 Common
33
+24 VDC output 34 +24 VDC output
35 +24 VDC output 36 Not connected
37 Not connected
J5 Plasma interface (Continued)
Pin No. Signal Pin No. Signal
