ArcGlide THC Instruction Manual 806450 219
4 – Maintenance
J7 Operator console interface
Pin No. Signal Pin No. Signal
1 Not connected 2 Manual disable switch input +
3 Manual select switch input + 4 Torch up switch input +
5 Torch down switch input + 6 Spare switch input +
7 Common 8 Torch enabled output A
9 Torch enabled output B 10 Error output A
11 Error output B 12 Spare output A
13 Spare output B 14 Power +24 VDC output
