Hypertherm Powermax65 SYNC Reference Guide

Serial Communication Programmer Reference Guide
Powermax65/85/105 SYNC Reference Guide 810400 35
0834 2100 (Fault code 2-10-0)
The inverter IGBT temperature sensor is open.
Yes
0835 2101 (Fault code 2-10-1)
The inverter IGBT temperature sensor short-circuited.
Yes
083E 2110 (Fault code 2-11-0)
The pressure sensor is open.
Yes
083F 2111 (Fault code 2-11-1)
The pressure sensor short-circuited.
Yes
0898 2200 (Fault code 2-20-0)
The DSP PCB does not recognize the torch.
Yes
0BB8 3000 (Fault code 3-00-0)
The DC bus voltage is out of range.
Yes
0C1C 3100 (Fault code 3-10-0)
The fan speed is less than the minimum speed.
Yes
0C1D 3101 (Fault code 3-10-1)
A fan fault occurred.
Yes
0C26 3110 (Fault code 3-11-0)
The boost PFC IGBT temperature sensor is open.
Yes
0C27 3111 (Fault code 3-11-1)
The boost PFC IGBT temperature sensor
short-circuited.
Yes
0C28 3112 (Fault code 3-11-2)
There is a boost PFC IGBT temperature sensor circuit
fault.
Yes
0C80 3200 (Fault code 3-20-0)
The fill valve is not connected.
Yes
0C81 3201 (Fault code 3-20-1)
The dump valve is not connected.
Yes
0C82 3202 (Fault code 3-20-2)
The plasma power supply does not recognize the
solenoid valve.
Yes
0C83 3203 (Fault code 3-20-3)
The electronic regulator is not receiving power.
Yes
0D52 3410 (Fault code 3-41-0)
A driver integrated circuit (IC) fault occurred.
Yes
0D5C 3420 (Fault code 3-42-0)
The 5 VDC or 24 VDC supply is out of range.
Yes
0D5D 3421 (Fault code 3-42-1)
The 18 VDC supply is out of range.
Yes
Fault Code
(hex)
Fault Code
(decimal)
Description
Steps Required to
Remove?
