Serial Communication Programmer Reference Guide 62 810400 Reference Guide Powermax65/85/105 SYNC
Figure 1 – Operator selects the plasma power supply type (SYNC / older)
COMMUNICATE USING
POWERMAX SYNC
0x3xxx ADDRESSING.
IF VALID
RESPONSE
IF NO
RESPONSE
POWERMAX IS NOT
POWERED ON.
CHECK FOR
FAULT.
REGISTER READ
0x0301A
EXIT
ENTER
IF VALID
RESPONSE
IF NO
RESPONSE
POWERMAX IS NOT
POWERED ON.
EXIT
CHECK FOR
FAULT.
REGISTER READ
0x0298
COMMUNICATE USING
OLDER 0x2xxx
ADDRESSING.
OLDER
SYNC
ON THE CNC GUI SETUP SCREEN, USER
MANUALLY SELECTS THE POWERMAX
FAMILY AND MODEL CONNECTED.
CNC USES
APPROPRIATE
ADDRESSING.
EXAMPLE REQUEST
:0104301A0001B0
EXAMPLE REQUEST
:01042098000142
