www.hysecurity.com © 2019 Troubleshooting MX3630-01 Rev. J 113
Type Alert/Fault/Error Display Buzzer Chirp Sequence
Possible Cause &
Suggested Corrective
Action
Solutions
ALERT ALERT 21
DRIVE TRIP
2 chirps per second every 15
seconds
Gate travel will not occur until
the alert is cleared. Any open
or close command resets the
alert and starts the gate moving,
unless the VFD is experiencing
a fatal error. If you cannot clear
the error alert by pressing the
open or close button, contact
HySecurity.
ALERT ALERT 22
INTLOCK FAILURE
2 chirps per second every 3
seconds
Appears when the RS-485
communication connection is
lost for more than 5s between
interlocked (dual gate) or
sequenced gate operators.
1. Check cable connections
and wiring. Make sure
both operators are working
properly and have compatible
software versions. The
alert auto clears when
communication between the
two operators is restored.
2. If the operator on site is a
singular gate and the display
code ALERT 22 appears,
access the Installer Menu.
Verify the Installer Menu
items: DG (Dual gate) and SG
(Sequential gate) are both set
to zero.
ALERT ALERT 24
EXT RELAY FAULT
2 chirps per second every 15
seconds
The Hy8Relay (extended relay
module) is not being recognized.
Alert noted in diagnostic log.
Check the wiring:
• Make sure the slide switch on
the side of the extended relay
module is set at “Normal.”
• (Y) Data + is connected to “A”
DUAL GATE.
• (G) DATA - is connected to “B”
DUAL GATE.
• Connector cable (4-pin)
attaches to RS-485.
If Hy8Relay module is not
connected, access the Installer
Menu. Check that the extended
user relays are set to zero.
STC = R4 to RB (7-segment
display)
SDC = R3 to R9 (32 character
display)
STC = R4 to R11 (32 character
display)
ALERT ALERT 25
LOW COIN BATT (HyNet)
N/A HyNet Only.
The HyNet coin battery is dying.
Turn off AC power to the HyNet
and replace the existing coin
battery with a CR1220 coin
battery. Turn On power to the
HyNet. The ALERT should reset
and disappear from the display.
