eMerGenCy fast Close
The Emergency Fast Close setting in combination with a constant hold to close, overrides vehicle detectors,
photo eyes and edge sensors and closes the barrier arm. To enable the Emergency Fast close option:
NOTE: When you are in programming mode the buttons on the keypad change from Open, Close, and
Stop to Previous, Next, and Select. Refer to Menu Mode Navigation on page 60.
1. Make sure the operator is turned ON and a Run mode status (ex., GATE OPEN)
appears on the Smart Touch Controller, which indicates the machine
is operational.
2. Press the Menu button twice to access the User Menu.
3. Press and hold the Reset button and then the Open button. Hold the buttons for
two seconds and then release both buttons. FO x appears on the display which
indicates you have accessed the Installer Menu.
4. Press Next until the Emergency Close OC 0appears on the display.
5. Press Select and OC starts blinking, which indicates the display can be changed.
6. Press Next or Previous to change the display to OC 1.
7. Press Select to accept the entry. (The display characters stop linking.)
8. Press Program to exit programming mode and return to Run mode.
A Run mode gate status appears (ex., GATE OPEN).
installinG a Push Button deViCe for eMerGenCy fast
oPerate (efo)
The Emergency Fast Close on the 50VF-series is designed for
a constant hold function, such as a push-button device that is held
for the duration of gate travel. To operate properly, the device
must be connected to Terminal 23 on the Smart Touch Controller
and a +24VDC terminal on the Power Supply Board.
When the connections are made, the constant hold signal
transmitted to the Smart Touch Controller activates the close
function. The gate closes at a higher speed than usual. Photo
eyes, vehicle loop inputs, and other safety devices (such as
external entrapment protection sensors) are ignored.
HYSECURITY
GATE OPEN
OC 1
EMERGENCY CLOSE
STOP BUTTON
OPEN BUTTON
CLOSE BUTTON
REMOTE OPEN AND
RADIO CONTROL
OPEN/CLOSE
1
OPEN PARTIAL
INTERLOCK OPEN
TIME CLOCK OPEN
FREE EXIT DETECTOR
DISABLE EXIT DETECTOR
DISABLE CLOSE TIMER
INSIDE OBSTRUCTION
VEHICLE DETECTOR
OUTSIDE OBSTRUCTION
VEHICLE DETECTOR
SHADOW/RESET
VEHICLE DETECTOR
SENSOR 1
SENSOR COM
DO NOT USE
DO NOT USE
DO NOT USE
CHARGER
AC LOSS
LOCK INTERLOCK
EMERG CLOSE
FIRE DEPT OPEN
2
3
4
5
6
7
8
9
10
11
12
14
15
16
17
18
19
20
21
22
23
24
Smart Touch Controller
LIMIT DUAL GATE
RADIO OPTIONS
DRIVE
POWER
RS485
MOTOR USER 1
USER 2
USER 3
VEHICLE DETECTORVEHICLE DETECTORVEHICLE DETECTOR
STOP/BUZZER
FREE EXIT
INSIDE OBSTR
OUTSIDE OBSTR
SHADOW RESET
WIEGAND
HySecurity
COM
NO
MX000585
VERSION
S/N
RS232
DISPLAY
VEHICLE DETECTOR
COM COMA B
RPM
COMOPEN S1+24V +24V
STAT US
LED
24V
A
C A
cce
ss
or
y powe
r
+
24V
D
C
Power Connector
Power Supply Board
C
O
MM
ON
Emergency Fast
Close Device
(Actuator)
SENSOR COM
SENSOR 2
SENSOR 3
