HySecurity Smart Touch User Manual

MX3657-01 Rev. D ©2020 STC Inputs & Wiring
hysecurity.com | 800-321-9947 75
STC Inputs & Wiring
This section provides information about the Smart Touch Controller, its inputs for peripheral connections, and
its monitoring capabilities. This section explains how to:
• Make Connections on the Smart Touch Controller
• Integrate with Security Systems
• Adapt User Relays for your Gate Site
STOP BUTTON
OPEN BUTTON
CLOSE BUTTON
REMOTE OPEN AND
RADIO CONTROL
OPEN/CLOSE
1
OPEN PARTIAL
INTERLOCK OPEN
TIME CLOCK OPEN
FREE EXIT DETECTOR
DISABLE EXIT DETECTOR
DISABLE CLOSE TIMER
INSIDE OBSTRUCTION
VEHICLE DETECTOR
OUTSIDE OBSTRUCTION
VEHICLE DETECTOR
SHADOW/RESET
VEHICLE DETECTOR
SENSOR 1
SENSOR COM
DO NOT USE
SENSOR 2
DO NOT USE
SENSOR 3
DO NOT USE
CHARGER
AC LOSS
LOCK INTERLOCK
EMERG CLOSE
FIRE DEPT OPEN
2
3
4
5
6
7
8
9
10
11
12
14
15
16
17
18
19
20
21
22
23
24
Smart Touch Controller
LIMIT DUAL GATE
RADIO OPTIONS
DRIVE
POWER
RS485
MOTOR USER 1
USER 2
USER 3
VEHICLE DETECTORVEHICLE DETECTORVEHICLE DETECTOR
STOP/BUZZER
FREE EXIT
INSIDE OBSTR
OUTSIDE OBSTR
SHADOW RESET
WIEGAND
HySecurity
COM
NO
MX000585
VERSION
S/N
RS232
DISPLAY
VEHICLE DETECTOR
COM COMA B
RPM
COMOPEN S1+24V +24V
STAT US
LED
Stop Button* - 1
Open Button* - 2
Close Button* - 3
Remote Open and Radio Control - 4
Open / Close - 5
Open Partial - 6
Interlock Open / Time Clock Open - 7
Free Exit Detector - 8
Disable Exit Detector / Close Timer - 9
Inside Obstruction Vehicle Detector - 10
Outside Obstruction Vehicle Detector - 11
Shadow / Reset Vehicle Detector - 12
Sensor 1 - 13
Sensor COM - 14
Sensor COM - 15
DO NOT USE - 16
Sensor 2 - 17
DO NOT USE - 18
Sensor 3 - 19
DO NOT USE - 20
Charger AC Loss - 21
Gate Lock Interlock - 22
Emergency Close** - 23
Fire Department Open** - 24
Tact Push Button Switch
CO
MM
ON
24V
A
C A
cce
ss
or
y powe
r
+
24
V
RS-485
Motor Relay
Reset & Buzzer Connector
User Relay 1
HY-5A Free Exit
User Relay 2
HY-5A Inside
Obstruction
User Relay 3 (DC Only)
Solid state for use with
flashers and other
high cycle accessories
Clock Battery
HY-5A Outside
Obstruction
HY-5A Shadow /
Reset*
RS-232 Connector
Weigand Connector
Limit Switch
Connectors
Master
Slave
Open
Radio
Gate
Edge Radio
LED lights
when energized
Power Connector
Power Supply Board
Hy5A
24V DC
Accessory Power (+)
Common Bus (-)
Heartbeat
Blinks green = operational
Red = alert, fault, or error
Hy5B Refer to the HySecurity
website for more information
about Hy5B installation and use.
Hy5B
