MX3657-01 Rev. D ©2020 STC Inputs & Wiring
hysecurity.com | 800-321-9947 83
Setting Performance Description Wire
Connection
19 Flasher Relay Flashes lights once per second. The relay is constantly
pulsing except when the open limit switch is triggered.
* Preferred connection is Relay 3, a solid state relay (except
on Crash). On Crash gate operators, Relay 3 is unavailable
because it is hard-wired for the LED barrier arm lights.
Relay 1 or 2*
(Relay 3)
20 Free Exit Loop Vehicle Detector
output
Active when the Free Exit Loop is tripped. Relay 1, 2 or 3
21 Inside Obstruction Vehicle Detector
output
Active when the Inside Obstruction loops is tripped. Relay 1, 2 or 3
22 Center Loop Detector output Active when the Reset/Center/Shadow loop detector is
tripped.
Relay 1, 2 or 3
23 External Latching gate Lock Output
(Prison Lock)
Activates when the Lock Interlock Input (Terminal No. 22)
is active at the start of an Open cycle and remains on until
the Lock Interlock releases or 10 seconds elapse, whichever
happens sooner. Also, activates a Close cycle and releases 1
second after reaching the Close limit.
Relay 1, 2 or 3
24 Gate at Partial Open Position Active when the partial open position is reached or
exceeded. Not used in StrongArmCrash.
Relay 1, 2 or 3
25 DC Power OK Alert Deactivates when the software detects a low battery voltage
(below 21VDC, but greater than 18VDC) for a duration of
2 seconds or more. To slow battery drain, accessory power
loads are shed.
Relay 3
26 Free Exit Vehicle Detector Pulse Activates when the Exit Loop Detector is tripped and causes
a 250mS pulse output to occur.
Relay 1, 2 or 3
27 Not Open (requires AC power) When AC power is detected, this relay activates when the
gate in NOT on the open limit. If AC power fails, or the gate
is on the open limit, the relay is deactivated.
Relay 1, 2 or 3
28 Flasher (requires AC power) Controls ashing lights that pulse 500ms per second. The
relay is constantly activating except when the open limit
switch is triggered or AC power fails.
Relay 1, 2 or 3
29 Set aside for Factory Use HySecurity Testing Only Do not use
30 Arm Breakaway Only used on StrongArm and StrongArmPark DC and
activates if the breakaway arm switch is tripped.
31 Warn Operate Run Relay is active while warn before and motor running. Relay 1 or 2
32 Partial Open Pulse Relay pulses when partial open activated and when partial
open limit reached. Often used at a sequential gate site.
Relay 1 or 2
33 Inbound Transient/Lot Output N.O. Input. The relay outputs a 250ms pulse used to
increment the transient and total vehicle counts. Refer
to the HySecurity Parking supplement for more detailed
information.
R1 and R2, R4
through R11
TRANSIENT
USER
34 Outbound Transient/Lot Output N.O. Input. The relay outputs a 250ms pulse used to
decrement the transient and total vehicle counts. Refer
to the HySecurity Parking supplement for more detailed
information.
R1 and R2, R4
through R11
TRANSIENT
USER
35 Inbound Tenant Output N.O. Input. The relay outputs a 250ms pulse and increments
the tenant counter when the Tenant User input is activated
and OALD, then CLD, are tripped and released. This activity
signals a prepaid customer has entered the facility.
R1 and R2, R4
through R11
TENANT USER
