Connect all power cords to a properly wired and grounded electrical outlet. Ensure that the outlet supplies proper
voltage and phase rotation according to the system rating plate.
Connect any equipment that will be attached to this product to properly wired outlets.
When possible, use one hand only to connect or disconnect signal cables.
Never turn on any equipment when there is evidence of fire, water, or structural damage.
Disconnect the attached power cords, telecommunications systems, networks, and modems before you open the device
covers, unless instructed otherwise in the installation and configuration procedures.
Connect and disconnect cables as described in the following procedures when installing, moving, or opening covers on
this product or attached devices.
To disconnect:
1. Turn off everything (unless instructed otherwise).
2. Remove the power cords from the outlets.
3. Remove the signal cables from the connectors.
4. Remove all cables from the devices.
To connect:
1. Turn off everything (unless instructed otherwise).
2. Attach all cables to the devices.
3. Attach the signal cables to the connectors.
4. Attach the power cords to the outlets.
5. Turn on the devices.
Sharp edges, corners and joints may be present in and around the system. Use care when handling
equipment to avoid cuts, scrapes and pinching.
(D005)
Attention: The 7226 Storage Enclosure is a precision device that requires reasonable care in handling to prevent data loss or
permanent damage to the device. Avoid bumping or dropping the 7226 Storage Enclosure. Ensure all media is removed from
the device before the enclosure is moved.
Performing the Installation
Performing the Installation
To install the 7226 Model 1U3 Storage Enclosure, complete the following steps.
Step 1. Using the Inventory Checklist
Step 2. Checking the Electrical Outlets
Step 3. Assembling the Materials
Step 4. Placing the 7226 Storage Enclosure
Step 5. Connecting the SAS, USB, or Fibre Channel Cables
Step 6. Connecting the Power Cables
Step 7. Performing the Checkout Procedure
Step 1. Using the Inventory Checklist
Make sure that you received the following items:
Power cable (for the appropriate cable see Power Cables)
SAS, USB, or Fibre Channel cables
Readme Sheet
Statement of Limited Warranty, 7226-1U3
Environmental Notice User Guide (ENUG) CD
Safety Important Notices Pointer
Quality Hotline Card
