System Specifications
The size, weight, and heat output specifications vary be model. The other system
specifications apply to both the 3-bay design and the 4-bay design.
Size
3-Bay Design
– Depth: 400 mm (15.8 in.)
– Height: 95 mm (3.7 in.)
– Width: 369 mm (14.5 in.)
4-Bay Design
– Depth: 420 mm (16.5 in.)
– Height: 110 mm (4.3 in.)
– Width: 440 mm (17.3 in.)
Weight
3-Bay Design
– Minimum configuration as shipped: 6.80 kg (15 lb)
– Maximum configuration: 8.16 kg (18 lb)
2
4-Bay Design
– Minimum configuration as shipped: 9.07 kg (20 lb)
– Maximum configuration: 11.3 kg (25 lb)
2
2
Maximum configuration weight depends on actual optional features installed. Figures shown are for a
system fully populated with typical optional features.
Chapter 1. Your IBM Personal Computer
13
