Electrical Input
5
Sine-wave input (50 to 60 Hz) is required
Input voltage for the 3-bay design:
– Low range:
- Minimum: 100 V ac at 3 A
- Maximum: 127 V ac at 3 A
- Voltage switch setting: 115 or 115 V
– High range:
- Minimum: 200 V ac at 1.5 A
- Maximum: 240 V ac at 1.5 A
- Voltage switch setting: 230 or 230 V
– Input kilovolt-amperes (kVA) (approximately):
- Minimum configuration as shipped: 0.08 kVA
- Maximum configuration: 0.30 kVA
Input voltage for the 4-bay design:
– Low range:
- Minimum: 100 V ac at 5 A
- Maximum: 127 V ac at 5 A
- Voltage switch setting: 115 or 115 V
– High range:
- Minimum: 200 V ac at 3 A
- Maximum: 240 V ac at 3 A
- Voltage switch setting: 230 or 230 V
– Input kilovolt-amperes (kVA) (approximately):
- Minimum configuration as shipped: 0.08 kVA
- Maximum configuration: 0.30 kVA
Power consumption varies depending on the number and type of optional features
installed and the power-management optional features in use.
5
Maximum power specifications are based on the maximum capacity of the system power supply, 85
watts for the 3-bay design and 145 watts for the 4-bay design.
Chapter 1. Your IBM Personal Computer
15
