The following modes are supported by your computer.
Notes:
1. 43, 45, and 49 Hz are interlaced (i); all other refresh rates shown are
noninterlaced.
2. If 2 MB of memory is required for the video mode, an optional 1 MB of memory
must be installed in the system board.
Some application programs require video device drivers to use SVGA modes. If your
computer has IBM-preinstalled software, the video device drivers are included and
instructions are provided online. If your software is not preinstalled, the video
device drivers are on the Ready-to-Configure CD.
Some application programs provide their own video device drivers to take
advantage of SVGA modes. These device drivers are installed through a setup
program built into the application program. Setting up these applications to operate
in SVGA modes might be confusing because terminology for these modes is not
consistent throughout the industry. If you are uncertain about the terminology used
by your application program, refer to the documentation that comes with the
application for additional information.
Resolution
(Pels)
Bits per
Pixel
Refresh Rates
(Hz)
Memory Required (MB)
640 x 480 8/15/16 60, 72, 75, 85 1
640 x 480 32 60, 72, 75, 85 2
800 x 600 8/15/16 60, 72, 75, 85 1
800 x 600 32 60, 72, 75, 85 2
1024 x 768 8 43i, 60, 70, 72, 75, 85 1
1024 x 768 15/16 43i, 60, 70, 72, 75 2
1280 x 1024 8 45i, 60, 72, 75 2
1600 x 1200 8 49i 2
48 Using Your Personal Computer
