Evaluation Board Manual
PPC750FX Evaluation Board Preliminary
Bills of Materials
Page 104 of 115
750FXebm_ch12.fm
June 10, 2003
12.2 Debugging Tools
Table 12-3 identifies components that are recommended as aids for hardware monitoring. None of these
components are shipped in the board package.
12.3 Auxiliary Materials
Table 12-4 identifies components that are included in the board package, but are not listed in the board BOM
(see Table 12-5). Examples of this type of component are the jumpers (shunts) installed on the board to
configure its functional characteristics.
Table 12-3. Debugging Tools
Quantity Description
1
184 Pin DIMM Analysis Probe
Vendor 1: FuturePlus Inc.
Vendor 1 P/N: FS2330-1
1
64 Bit PCI-X Analysis Probe (Passive)
Vendor 1: FuturePlus Inc.
Vendor 1 P/N: FS2005
3
High Density Termination Adapter
Vendor 1: HP
Vendor 1 P/N: E5346A
Table 12-4. Auxiliary Materials in Kit
Quantity Part Number Supplier Description
2 AM29LV040B-70JC AMD Flash EEPROM, 512K x 8, 3V
1 1-382811-6 AMP/Tyco Standard shunt, 2.54mm
4 86730-001 FCI-Berg Miniature shunt, 2mm
2 31D1-164000 CableWholesale DB9 to RJ12 adapter cable
2 H2663-07-ND Digi-Key RJ12 modular cable
1 68P4504 IBM PCI I/O plate
1 68P4505 IBM System controller module heat sink
1 68P4513 IBM System controller module backplate
1 68P4509 IBM System controller module backplate insulator
2 68P4506 IBM Processor module heat sink
1 68P4512 IBM Processor module backplate
1 68P4510 IBM Processor module top insulator
1 68P4511 IBM Processor module backplate insulator
1 EFB0405HHA Delta Fans Fan, 40x40x10, 5VDC
12 91771A059 McMaster-Carr Mounting screw, 1/2 in., 0-80, Flathead
2 91241A412 McMaster-Carr Mounting screw, 1/4 in., 4-40, Flathead
4 90353A148 McMaster-Carr Mounting screw, M3-20, Panhead
4 95610A130 McMaster-Carr Washer, M3, nylon
