6.2 ATX Power-on Pushbutton
When pressed, the pushbutton switch at U53 generates a power-on signal to the external ATX power supply
connected to J34. This pushbutton must be pressed after the ATX power supply is connected to J34 in order
to activate the power supply
Note: If the board is plugged into a PCI slot, the external ATX power supply will not activate under any
conditions, and pressing U53 will have no effect.
6.3 CPU 0 PLL Configuration
An 8-position DIP switch at location U30 configures the PLL for the first PPC750FX processor (U1).
Table 6-3. Reset Pushbutton—U53
Signal Description (0 = ON = close)
PS_ON Generates power-on signal to the external ATX power connector.
Table 6-4. CPU 0 PLL Configuration—U30
Switch No. Signal Default Setting Description (0 = ON = closed, 1 = OFF = open)
1 PLL_CONFIG0 ON
Refer to the latest version of the PowerPC 750FX
RISC Microprocessor Data Sheet for details on the bit
settings for PLL_CONFIG and PLL_RANGE.
2 PLL_CONFIG1 OFF
3 PLL_CONFIG2 ON
4 PLL_CONFIG3 OFF
5 PLL_CONFIG4 OFF
6 PLL_RANGE0 ON
7 PLL_RANGE1 ON
8 SPARESWITCH1 ON
Input to CPLD F2 pin with pull-up to +3.3V. See CPLD
Register1.
