11.2 Timing—Registers and Control Functions
The timing data in the following tables are based on simulation.
11.2.1 Maximum Clock Frequency
Table 11-4 provides the actual frequency at which the indicated clock is running, and the highest frequency at
which it can be allowed to run before the period becomes shorter than the worst case signal propagation time.
11.2.2 Clock-to-Output Time
Table 11-5 provides the longest and shortest input-to-output delay for each output signal clocked through a
register for the all clocks that gate the signal.
Table 11-4. Maximum Clock Frequency
Clock Actual Operating Frequency Allowed Maximum Frequency (period)
pld25mhz 25MHz 166.67MHz (6ns)
dev_we_n[0] None 181.82MHz (5.5ns)
pld_sysclk 133.33MHz 185.19MHz (5.4ns)
Table 11-5. Clock-to-Output Time
Output Signal Clock Longest Delay (ns) Shortest Delay (ns)
big_flash_cs_n ale 9.100 9.100
cpu_mcp0 dev_we_n[0] 10.900 10.900
cpu_mcp1 dev_we_n[0] 10.900 10.900
cpu_tben dev_we_n[0] 10.900 10.900
cpu_trst_n pld25mhz 26.400 18.500
cpu0_hreset_n dev_we_n[0] 15.500 15.500
cpu0_hreset_n pld25mhz 23.100 15.200
cpu0_smi_n dev_we_n[0] 10.900 10.900
cpu0_sreset_n dev_we_n[0] 14.700 14.700
cpu0_sreset_n pld25mhz 14.500 14.400
cpu1_hreset_n dev_we_n[0] 19.200 19.200
cpu1_hreset_n pld25mhz 26.800 18.900
cpu1_smi_n dev_we_n[0] 10.900 10.900
cpu1_sreset_n dev_we_n[0] 14.700 14.700
cpu1_sreset_n pld25mhz 14.500 14.400
dev_adr[0] ale 12.500 12.500
dev_adr[0] dev_we_n[0] 9.500 9.400
dev_adr[1] ale 12.500 12.500
dev_adr[1] dev_we_n[0] 9.400 9.400
dev_adr[2] ale 12.500 12.500
