Evaluation Board Manual
Preliminary PPC750FX Evaluation Board
750FXebm_ch3.fm
June 10, 2003
Memory Map
Page 27 of 115
3. Memory Map
Table 3-1 provides a summary of the board address space usage. For details about address space usage
relating to the processor registers, refer to the PPC750FX Embedded Processor User’s Manual.
3.1 CPLD Register Definitions
This section provides description by bit for each of the CPLD registers.
Each CPLD register is 8 bits wide. In the tables below, the most significant bit is bit 0, and the least significant
bit is bit 7. The CPLD source code uses the reverse bit ordering.
Table 3-1. Board Address Space Usage
Peripheral Start Address End Address Chip Select Size
DDR SDRAM 0x00000000 0x0FFFFFFF SDRAM CS0 and CS1 256MB
MV64360 Integrated SRAM 0x42000000 0x4203FFFF n/a 256KB
FRAM 0xEF500000 0xEF507FFF DevCS3 32KB
ST16C2552 UART Channel B 0xEF600000 0xEF600007 DevCS2 8B
ST16C2552 UART Channel A 0xEF600008 0xEF60000F DevCS2 8B
CPLD Registers 0xEF700000 0xEF700004 DevCS1 5B
MV64360 Registers 0xF1000000 0xF100FFFF n/a 64KB
32-bit Flash 0xFC000000 0xFDFFFFFF DevCS0 32MB
SRAM 0xFFE00000 0xFFEFFFFF BootCS 1MB
8-bit Flash 0xFFF00000 0xFFFFFFFF BootCS 1MB
Note: The base addresses of peripherals attached to the MV64360 system controller device are software dependent. The values in the
table above are used by the PPC750FX Evaluation Kit Software. Other software environments may use different values for the
peripheral base addresses.
Table 3-2. Register0
Bit Name R/W Description
0:7 CPLD Revision R Revision level of CPLD code
