Evaluation Board Manual
PPC750FX Evaluation Board Preliminary
Programming the System Controller
Page 36 of 115
750FXebm_ch4.fm
June 10, 2003
4.2.5 Boot Device Parameters (8 bit flash and SRAM)
If booting from the 8-bit Flash or SRAM, the default value of the Boot Device Parameters register in the
system controller is 0x8FCFFFFF. To improve the access time to the Flash contents, the register can be
changed to the following:
Table 4-6. Boot Device Bank Parameters = 0x8185D09E
Field Value (bin) Comment
TurnOff 110
Number of Sysclk cycles that the system controller does not drive the
address/data bus after completion of a device read
Acc2First 0011
Number of Sysclk cycles from the de-assertion of ALE to the cycle that the
first read data is sampled
Acc2Next 010
Number of Sysclk cycles in a burst read access between the cycle that
samples data N to the cycle that samples data N+1
ALE2Wr 010 Number of Sysclk cycles from ALE de-assertion to the assertion of Wr[0]
WrLow 111 Number of Sysclk cycles that Wr[0] is active
WrHigh 010
Number of Sysclk cycles between data beats of a burst write that Wr[0] is
held in-active. BAdr and data are held valid for WrHigh-1 cycles
DevWidth 00 Device width of 8 bits
TurnOffExt 0 TurnOff extension (most significant bit)
Acc2FirstExt 1 Acc2First extension (most significant bit)
Acc2NextExt 1 Acc2Next extension (most significant bit)
ALE2WrExt 0 ALE2Wr extension (most significant bit)
WrLowExt 0 WrLow extension (most significant bit)
WrHighExt 0 WrHigh extension (most significant bit)
BadrSkew 00 Number of Sysclk cycles from when BAdr changes to the read of the data
DPEn 0 Parity Disabled
Reserved 1
