IBM PPC750FX User Manual

Evaluation Board Manual
Preliminary PPC750FX Evaluation Board 750FXebm_ch12.fm June 10, 2003 IBM Confidential
Bills of Materials
Page 109 of 115
1.0K 22 R116, R237, R308, R309,
R332, R352, R424, R426,
R427, R431, R438, R444,
R445, R447, R450, R520,
R524, R527, R528, R532,
R534, R537
SMER0402 PANASONIC ERJ2RKF1001X PHYCOMP 9C1A04021001F
LHF3
--
200 5 R3, R4, R15, R16, R533 SMER0805R PANASONIC ERJ6GEYJ201V PHILIPS 232273061201 ROHM MCR10EZHJ201
0 6 R224, R226, R267, R271,
R307, R312
SMER1206R PANASONIC ERJ8GEYOR00V ROHM MC18EZHJ000 AVX CJ32-000-T
100 3 R243, R256, R257 SMER0805R PANASONIC ERJ6ENF1000V ROHM MCR10EZHF100
0
PHILIPS 232273461001
1K 1 R247 SMER0805R ROHM MCR10EZHJ102 PANASONIC ERJ6GEYJ102V PHILIPS 232273061102
1.30K 1 R251 SMER0402 PANASONIC ERJ-2RKF1301X DIGIKEY P1.30KLCT-ND - -
10K 1 R252 SMER0805R PANASONIC ERJ6GEYJ103V ROHM MCR10EZHJ103 PHILIPS 232273061103
200 4 R253, R259, R310, R314 SMER0402 YAGEO 9C04021A2000JL
HF3
PANASONIC ERJ-2GEJ201X DIGIKEY P200JCT-ND
33.2 2 R261, R262 SMER0402 PANASONIC ERJ-2RKF33R2X - - - -
49.9 10 R264, R265, R269, R270,
R289, R296, R301, R305,
R306, R463
SMER0402 PHYCOMP 9C1A040249R9FL
HF3
PANASONIC ERJ-2RKF49R9X - -
340K 2 R273, R313 SMER0402 VENKEL CR0402-16W-
3403FT
-- --
0 15 R278, R281, R284, R287,
R299, R359, R372, R373,
R396, R400, R401, R419,
R508, R509, R538
SMER0402 PANASONIC ERJ2GE0R00 - - - -
10 1 R325 SMER0805R PHILIPS 232273061109 PANASONIC ERJ6GEYJ100V ROHM MCR10EZHJ100
1.5K 14 R334-R336, R342, R343,
R345, R347, R349, R357,
R358, R360-R362, R371
SMER0402 PHYCOMP 9C04021A1501FL
HF3
PANASONIC ERJ-2RKF1501X - -
470 4 R353, R354, R388, R471 SMER0402 PANASONIC ERJ2GEYJ471V YAGEO 9C04021A4700JL
HF3
DIGIKEY ERJ-2GEJ471X
100K 1 R363 SMER0805R PANASONIC ERJ6GEYJ104V ROHM MCR10EZHJ564 AVX CR21-564J-T
12.1K 1 R384 SMER0402 DIGIKEY 311-12.1KLTR-ND YAGEO 9C04021A1212F
LHF3
--
10K-5% 5 R423, R425, R428, R432,
R536
SMER0402 PANASONIC ERJ-2GEJ103X PHYCOMP 9C1A04021002JL
HF3
--
36 1 R480 SMER0402 YAGEO
AMERICA
9C04021A36R0FL
HF3
-- --
10 2 R485, R486 SMER0402 PANASONIC ERJ2GEJ100X PHYCOMP 9C1A040210R0J
LHF3
--
100K 1 R53 SMER0402 PANASONIC ERJ2RKF1003X PHYCOMP 9C1A04021003F
LHF3
--
Table 12-5. Evaluation Board Bill of Materials (Continued)
DNP Value Qty Ref Des JEDEC Type Vendor Vendor PN ALT1 Vendor ALT1 Vendor PN ALT2 Vendor ALT2 Vendor PN
