Table 18. IMM2 error messages (continued)
v Follow the suggested actions in the order in which they are listed in the Action column until the problem is
solved.
v If an action step is preceded by “(Trained technician only),” that step must be performed only by a trained
technician.
80010b01-1401xxxx
80010b01-1402xxxx
Sensor CPU n VR
Temp going high
(upper
non-recoverable) has
asserted. (n =
microprocessor
number)
Error An upper
non-recoverable
sensor going high
has asserted.
Check the server airflow. Make sure
that nothing is blocking the air from
coming into or preventing the air from
exiting the server.
80010701-2d01xxxx Numeric sensor PCH
Temp going high
(upper non-critical)
has asserted.
Warning An upper
non-critical sensor
going high has
asserted.
1. Reduce the ambient temperature.
2. Check the server airflow. Make sure
that nothing is blocking the air from
coming into or preventing the air
from exiting the server.
80010901-2d01xxxx Numeric sensor PCH
Temp going high
(upper critical) has
asserted.
Error An upper critical
sensor going high
has asserted.
1. Reduce the ambient temperature.
2. Check the server airflow. Make sure
that nothing is blocking the air from
coming into or preventing the air
from exiting the server.
80010b01-2d01xxxx Numeric sensor PCH
Temp going high
(upper
non-recoverable) has
asserted.
Error An upper
non-recoverable
sensor going high
has asserted.
Check the server airflow. Make sure
that nothing is blocking the air from
coming into or preventing the air from
exiting the server.
81010701-2d01xxxx Numeric sensor PCH
Temp going high
(upper non-critical)
has deasserted.
Info An upper
non-critical sensor
going high has
deasserted.
No action; information only.
81010901-2d01xxxx Numeric sensor PCH
Temp going high
(upper critical) has
deasserted.
Info An upper critical
sensor going high
has deasserted.
No action; information only.
81010b01-2d01xxxx Numeric sensor PCH
Temp going high
(upper
non-recoverable) has
deasserted.
Info An upper
non-recoverable
sensor going high
has deasserted.
No action; information only.
80010204-1d01xxxx
80010204-1d02xxxx
80010204-1d03xxxx
80010204-1d04xxxx
80010204-1d05xxxx
80010204-1d06xxxx
80010204-1d07xxxx
80010204-1d08xxxx
80010204-1d09xxxx
80010204-1d0axxxx
80010204-1d0bxxxx
80010204-1d0cxxxx
Numeric sensor Fan
n A Tach going low
(lower critical) has
asserted. (n = 1Aa,
1Ab, 2Aa, 2Ab, 3Aa,
3Ab)
Error A lower critical
sensor going low
has asserted.
1. Reseat the failing fan n, which is
indicated by a lit LED near the fan
connector on the system board.
2. Replace the failing fan (see
“Removing the fan assembly” on
page 42 and “Replacing the fan
assembly” on page 412).
(n = fan number)
Chapter 4. Troubleshooting 175
