Installing and Removing PC Cards
2
Insert the PC Card into an appropriate slot according to your
PC Card type. Slot covers open to the inside when you insert
the PC Card.
If you are using a Type I or Type II PC Card, insert it into
either the upper slot 1 or the lower slot 2 .
If you are using a Type III PC Card, insert the card into the
lower
slot 2 .
1
2
3
Press the PC Card firmly into the connector until the eject
button 1 pops out. Then, pull the eject button out slightly and
fold it to the left.
1
2
1
Refer to the following sections:
To use PC Cards, see “Using PC Cards” on page 44.
To use PC Cards with power-saving functions, see:
– “Considerations for Suspend Mode” on page 96.
– “Considerations for Hibernation Mode” on page 98.
To secure your PC Card with a lock, see “Using the PC Card
Lock” on page 118.
Chapter 6. Installing and Removing Options 123
