FID 87 FID FE
aaaa bbbb cccc
ddddd Days hh:mm:ss
--OR--
yyyy:mm:dd VOLSER: nnnnnn
Table 104: CE FID FE Log menu
Function Next menu
Cancel or No Entries “CE Logs menu (CE Offline Mode)” on page 133
CLEAR LOG “CE Logs menu (CE Offline Mode)” on page 133
CURRENT TIMESTAMP
ddddd Days hh:mm:ss
– – OR – –
yyyy:mm:dd
“CE Logs menu (CE Offline Mode)” on page 133
FID 87 FID FE
3601 3335 243A
0010 13:05:12
VOLSER: 156M95
“CE Logs menu (CE Offline Mode)” on page 133
Cancel
Causes the “CE Logs menu (CE Offline Mode)” on page 133 to display.
No Entries
Indicates that no entries are in the error log. Choosing this option causes “CE Logs menu (CE Offline
Mode)” on page 133 to display.
CLEAR LOG
Allows the CE to erase the error log. This option is displayed only when there is at least one entry in
the error log. Choosing this option causes “CE Logs menu (CE Offline Mode)” on page 133 to display.
CURRENT TIMESTAMP
Provides a current time stamp that depicts when the error occurred. For a full description of this eld,
see “Time stamp for CE Error Log” on page 135.
FID yy yy
This example indicates a possible fault with the device associated with a FID yy. The characters of
support data include the fault symptom codes (aaaa and bbbb), and the model number (c), followed
by the microcode link (ccc). A time stamp follows. The last entry is the Volume Serial number. If the
Volume Serial number is not known, it shows "UNKNOWN". Choosing this option causes “CE Logs
menu (CE Offline Mode)” on page 133 to display.
Only the last 10 entries in the log are displayed. If a fault is detected and the log contains 10 entries, the
oldest entry is dropped from the end and the newest error is put in position 1 (the rst position in the list).
CE FID FF Log menu
The FID FF Log creates and holds a ltered subset of all sense data sent to the host with a FID of FF.
Table 105 on page 137 shows an example of the menu when the log contains entries. See “CE Error Log
menu” on page 134 for format information. The format is:
FID 85 FID FF
aaaa bbbb cccc
ddddd Days hh:mm:ss
– – OR – –
yyyy:mm:dd VOLSER: nnnnnn
136
IBM 3592 TS1140, TS1150, TS1155, and TS1160 Tape Drives: Maintenance Information
