IBM TS1160 User Manual

2
A
C
B
1
5
3
4
a05m0229
6
Figure 53: Label locations. Use with Table 136 on page 159.
Table 136: Label names and locations.
Use with Figure 53 on page 159.
Item
number Label name Additional information
1 Safety label
2 Label set
• A Model
• B Ports
• C LED status
Contains three items
3 RID (Repair IDentication) tag (FRU) Not present if 4 is installed
4 Serial number and machine type
label
Not present on FRU, or if 3 is installed
5 Serial number, machine type, and EC
label
6 Part number, machine type, and bar
code label
Safety and Inspection 159
