Table 20: Meaning of SIM severity codes (continued)
1 (FID3) Problem is moderate. Drive is operating in a degraded condition.
2 (FID2) Problem is serious. Drive is operating in a degraded condition.
3 (FID1) Problem is acute. Drive requires immediate service attention.
Figure 11: SIM format - sample. Use with Table 21 on page 40.
Table 21: SIM
elds descriptions. Use with Figure 11 on page 40.
Locator number Field name Field data or references
1 SIM/MIM Present
00
No SIM or MIM present.
01
SIM present.
02
MIM present.
2 Microcode and Link Level -
3 Message Code See “Message codes” on page 45
4 Exception Message See “SIM exception messages” on
page 46
5 Service Message See “SIM/MIM service messages” on
page 46
6 Severity See “SIM/MIM severity” on page 47
7 FRU Identier (FID) See “FID entry point” on page 6
8 First FSC -
9 Last FSC -
10 Sequence Number -
40 IBM 3592 TS1140, TS1150, TS1155, and TS1160 Tape Drives: Maintenance Information
