Table 16: LED indicators for EH7/EH8/55F/60F (continued)
2 Drive status Yellow
• Cartridge status not
indicated
• No message or error
• POR diagnostic in
progress
• Cartridge not
present
• Message or error
• POR diagnostic
completed
• Cartridge not
present
• No message or error
• POR diagnostic
completed
Green
• Cartridge present
• No message or error
• POR diagnostic
completed
• Cartridge present
• Message or error
• POR diagnostic
completed
3 Ethernet
communi-
cation
1
Yellow N/A N/A No communications
since last POST of
drive
Green N/A Ethernet
communication
activity
4 Information
2
Blue N/A N/A N/A
5 Port 0 - Fibre
Channel
activity
Yellow N/A Fibre Channel
connections are good;
not ready to transmit
• No light is detected
through Fibre
Channels
• Fibre Channel cable
is disconnected
• Port is not in use
• Fibre wrap plug is
installed on the port
• Drive was not
returned to operator
mode (is still in CE
offline mode or CE
online mode)
Green Fibre Channel
connections are
detecting light, but no
data is being
transferred. Wrap
tools are installed or
drive canister is offline
to host.
Fibre Channel
connections are good;
data is being
transferred
6 Port 1 - Fibre
Channel
activity
Yellow N/A Fibre Channel
connections are good;
not ready to transmit
Green Fibre Channel
connections are
detecting light, but no
data is being
transferred. Wrap
tools are installed or
drive canister is offline
to host.
Fibre Channel
connections are good;
data is being
transferred
Notes:
1. The Ethernet Communication LED is always off unless the CE or the customer is connected to the
Ethernet port at the front of the enclosure.
2. The Information LED is not lit. However, even if it is, it is not a cause to replace the drive. If it is on,
the fan is probably running at full speed.
Power supplies
32
IBM 3592 TS1140, TS1150, TS1155, and TS1160 Tape Drives: Maintenance Information
