Table 124 on page 149 shows the CE Select Address menu items. This menu allows the CE to select an

address in control store. The byte is read from the selected address. The message line indicates that the

Control Store option was selected on the previous screen.

Table 124: CE Select Address menu

Function Next menu

Cancel “CE Utilities menu” on page 138 or “CE Engr Use Only menu” on page

145

CS Adr (8 characters that are

displayed vertically)

Continue… “Display Memory menu” on page 149 or “CE Display/Alter menu” on

page 150

Note:

1. Supplemental Message Line 1: Control store

2. Supplemental Message Line 2: <none>

Cancel

Causes the “CE Utilities menu” on page 138 or “CE Engr Use Only menu” on page 145 to display.

Denes the address to be chosen. To change the value of the nibble, select the nibble, which causes a

new menu to display where you can select ‘0 - F'.

Continue…

Uses the address that is displayed and goes to “Display Memory menu” on page 149 or “CE Display/

Alter menu” on page 150.

Display Memory menu

Note: Use this only when directed by your next level of support.

Table 125 on page 149 shows the Display Memory menu items. This menu allows the CE to display the

byte in the specied address. The message line indicates the current control store address and value.

Table 125:

Display Memory menu

Function Next menu

Cancel “CE Utilities menu” on page 138

Scroll Up -

<CS ADR+0)> <CS Data> -

<CS ADR+4)> <CS Data> -

<CS ADR+8)> <CS Data> -

<CS ADR+…0)> <CS Data> -

Scroll Down -

Note:

1. Supplemental Message Line 1: SC Adrs: <CS Adrs>

2. Supplemental Message Line 2: SC Value: <CS Data>

Virtual Operator panel 149

IBM TS1160 User Manual
