Table 145: Fibre Channel WWID history log example and worksheet
Drive serial
number
0 Node names 1 0 Port names 1
1 2 3 4 5
00010011 5005076302000143 5005076302C00143 5005076302400143 5005076302800143
Displaying WW names
Note: Refer to “Supplemental Messages” in Table 44 on page 79 for bre-addressing information.
1. Press Mode Change . At the Conrm Mode Change menu, select CE Offline Mode > Cong/Install
> Drv Options > Drv Serial No.
2. Select Disp Serial No, and record the serial number in Table 145 on page 207.
Table 146:
DRV Serial No menu
CE DRV SERIAL NO J1A-F
►CANCEL
DRV SERIAL
000000010011
PORT0 ID:––23 OFFLINE
PORT1 ID:—–23 OFFLINE
3. Select Cancel, as necessary to return to the CE Cong/Install menu.
4. Select the Fibre Options menu.
5. Select Port/ Node Names. Record the node names and the port names in Table 145 on page 207.
Table 147:
Node Name menu
PORT NODE NAMES J1A-F
►Port Names/WWID
0=5005076302400143
1=5005076302800143
Node Names/WWID
0=5005076302000143
1=5005076302C00143
PORT0 ID:––23 OFFLINE
PORT1 ID:—–23 OFFLINE
6. Press Enter to return to the Fibre Options menu.
7. Return the drive to the Operator Mode, and place the drive online.
8. Return to the procedure that sent you here.
