PANEL DESCRIPTION
2
t CHANNEL GROUP INDICATOR (p. 8)
Indicates whether an U.S.A. “
USA,” International “INT,”
Canadian “
CAN” or weather “WX” channel is in use.
y CALL CHANNEL INDICATOR (pp. 7, 10)
Appears when the call channel is selected.
u LOW BATTERY INDICATOR
Blinks when the battery voltage drops to approx. 10 V DC
or below.
i CHANNEL NUMBER READOUT
Indicates the selected operating channel number.
o CHANNEL COMMENT INDICATOR
Channel comment appears if programmed. (p. 11)
!0 TIME ZONE INDICATOR
➥ Shows the current time data when a GPS receiver is
connected, or the time data is manually programmed.
• “??” may blink every 2 sec. instead of current time data
when the GPS current time data is invalid. After 23.5 hours
have passed, “No Time” will appear.
• “??” may blink every 2 sec. instead of current time data,
after 4 hours have passed from the time that was manually
programmed. The manually programmed time data is held
for 23.5 hours only, and after that, “No Time” will appear.
➥ “Local” appears when the offset time data is set.
(p. 38)
➥ “No Time” appears when no GPS receiver is con-
nected and no time data is input manually.
!1 POSITION INDICATOR
➥
Shows the current position data when a GPS receiver
is connected, or the time data is manually programmed.
•
“??” may blink every 2 sec. instead of position data, when
the GPS position data is invalid. The last position data is held
for 23.5 hours only, and after that, “
No Position
” will ap-
pear.
• “??” may blink every 2 sec. instead of data, after 4 hours
have passed from the time that is manually programmed.
The manually programmed position data is held for 23.5
hours only, and after that, “No Position” will appear.
➥ “No Position” appears when no GPS receiver is
connected and no position data is input manually.
!2 SCAN INDICATOR
➥ “PRI-SCAN 16” appears during Priority scan;
“NORMAL SCAN” appears during Normal scan. (p. 15)
➥ “DUAL 16” appears during Dualwatch; “TRI 16” ap-
pears during Tri-watch. (p. 13)
!3 SCRAMBLER INDICATOR (p. 12)
Appears when the voice scrambler function is activated.
(only when the optional scrambler unit is installed.)
!4 LOCAL INDICATOR (p. 9)
Appears when the Attenuator function is turned ON.
!5 BUSY/TRANSMIT INDICATOR (p. 9)
➥ “BUSY” appears when receiving a signal or when the
squelch opens.
➥ “TX” appears while transmitting.
