CHAPTER_CONTINUED
!4 KEY INDICATOR (p. )
Shows the programmed function of the soft keys on the
front panel.
!5 TIME ZONE INDICATOR (p. 2)
Shows the current time data when a GPS receiver is ➥
connected, or the time data is manually programmed.
•WhentheGPScurrenttimedataisinvalid,??mayblinkev-
ery 2 seconds instead of current time data. After 23.5 hours
have passed, “No Time” will appear.
•??mayblinkevery 2 instead of current time data, after 4
hours have passed from the time when the time data was
manually programmed. The manually programmed data is
held for only 23.5 hours, and after that, “No Time” will ap-
pear.
“Local” appears when the offset time data is set. ➥
(p. 44)
“No Time” appears when no GPS receiver is connected ➥
and no time data is manually input.
!6 POSITION INDICATOR (p. 2)
Shows the current position data when a GPS receiv- ➥
er is connected, or the position data is manually pro-
grammed.
•WhentheGPSpositiondataisinvalid,“??”mayblinkevery2
seconds instead of position data. The last position data is held
for only 23.5 hours, and after that, “No Position” will appear.
•“??” may blink every 2 seconds instead of position data, af-
ter 4 hours have passed from the time when the position data
is manually programmed. The manually programmed position
data is held for only 23.5 hours, and after that, “No Position” will
appear.
“No Position” appears when no GPS receiver is con- ➥
nected and no position data is input manually.
!7 SCAN INDICATOR (p. 2)
“SCAN 16” appears during a Priority scan; “SCAN” ap- ➥
pears during a Normal scan. (p. 17)
“DUAL 16” appears during Dualwatch; “TRI 16” appears ➥
during Tri-watch. (p. 18)
!8 BATTERY INDICATOR
Indicates the battery's remaining power.
