■ Battery pack replacement
q Before replacing the battery
pack, push and hold [PWR]
for 1 sec. to turn the power
OFF.
w Slide the battery release forward, then pull the battery pack
upward with the transceiver facing away from you.
DD
BATTERY PACKS
*
1
Operating periods are calculated under the following conditions;
Tx : Rx : standby =1 : 1 : 8, power save function: auto setting is
activated
*
2
Operating period depends on the alkaline cells used.
Battery
Voltage Capacity
Battery life*
1
pack
IC-V82 IC-U82
BP-208N
Battery case for AA
—*
2
(LR6)×6 alkaline
BP-209N 7.2 V 1100 mAh 3 hrs. 20 min. 3 hrs. 40 min.
BP-210N 7.2 V 1650 mAh 6 hrs. 7 hrs.
BP-211N 7.4 V 1800 mAh 6 hrs. 10 min. 8 hrs. 15 min.
BP-222N 7.2 V 600 mAh 2 hrs. 15 min. 2 hrs. 50 min.
Push and
hold for 1 sec.
PWR
