SPECIFICATIONS
14
15
GENERAL
• Frequency coverage : (unit: MHz)
USA Tx: 144–148/Rx: 136–174*
Europe, Taiwan, Korea Tx/Rx: 144–146
General (LM), CSA (LM) Tx/Rx: 136–174*
*Guaranteed: 144–148 MHz range only.
•Type of emission : FM
• Number of memory channels : 207 (incl. 6 scan edges and 1 call)
• Frequency resolution : 5, 10, 12.5, 15, 20, 25, 30, 50 kHz
• Operating temperature range : –10°C to +60°C; +14˚F to +140˚F
•Frequency stability : ±2.5 ppm
(–10°C to +60°C)
• Power supply requirement : 7.2 V DC (6–10.3 V DC acceptable;
Icom’s battery pack only)
• Current drain (at 7.2 V DC: approx.)
:
Transmit at 7 W (High) 2.6 A
at 4 W (Middle) 2.0 A
at 0.5 W (Low) 1.0 A
Receive standby 80 mA
power save 30 mA
max. audio 250 mA
• Antenna connector : BNC
(50 Ω)
• Dimensions (proj. not included) : 54(W) × 139(H) × 36.7(D) mm
2
1
⁄8(W)×5
15
⁄32(H)×1
7
⁄16(D) in
•Weight (approx.) : 390 g; 13.8 oz
(with BP-222N and Ant.)
200 g; 7.1 oz
(without battery pack and Ant.)
• Ext. data connector : 3-conductor 2.5 (d) mm (
1
⁄10″)
TRANSMITTER
• Modulation system : Variable reactance frequency mod.
• Output power (at 7.2 V) : 7 W/4 W/0.5 W (High/Mid/Low)
• Max. frequency deviation : ±5.0 kHz [Wide]/±2.5 kHz [Narrow]
• Spurious emissions : Less than –60 dBc
• Microphone connector : 3-conductor 2.5 (d) mm (
1
⁄ 10 ″)/2.2 kΩ
RECEIVER
• Receive system : Double-conversion superheterodyne
• Intermediate frequencies : 1st: 46.35 MHz, 2nd: 450 kHz
• Sensitivity
(at 12 dB SINAD) : 0.16 µV typical
• Squelch sensitivity
(threshold) : 0.11 µV typical
• Selectivity :
[Wide] More than 55 dB
[Narrow] More than 50 dB
• Spurious and image rejection : 80 dB typical
• Intermodulation : 65 dB typical
• Audio output power : More than 0.3 W at 10% distortion with
(at 7.2 V DC) an 8 Ω load
• Ext. speaker connector : 3-conductor 3.5 (d) mm (
1
⁄8″)/8 Ω
All stated specifications are subject to change without notice or obligation.
