56
11
DIGITAL MODE OPERATION
DD
Tx message programming
At least one of the Tx message channels must be pro-
grammed, if you want to use the GPS message. The GPS
message is transmitted from Tx message channels.
q While in
OPTION SET MODE
, push [
YY
] or [
ZZ
] several times
to select “tXm,” then push and hold [0•
OPT
] for 1 sec. to
edit the message indication, and then rotate [VOL] to se-
lect the message channel.
• One of either “C1” to “C6” blinks.
w Push [
YY
] to select message programming mode.
• The 1st digit blinks and channel indication stops blinking.
e Rotate [VOL] to set the desired character.
r Push [
YY
] to select 2nd digit, then rotate [VOL] to select
the desired character.
• 2nd digit blinks (1st digit stop blinking).
• Repeat this step for programming.
t Push [0•
OPT
] to save the message.
y Repeat steps w to t to set another message channels.
u Push [✱•
ENT
] (or [D•
CLR
])
to exit
OPTION SET MODE
.
• Available characters
DD
Rx message indication
When an individual station call with message is received, the
message can be stored into the Rx message record, up to 6
records and each record can indicate a message of up to 20
characters. The oldest record is overwritten when another
message is received.
q While in
OPTION SET MODE
, push [
YY
] or [
ZZ
] several times
until “RXm” appears.
w Push and hold [0•
OPT
] for 1 sec. to edit the message indi-
cation, and then rotate [VOL] to select the message
recored.
• One of either “C1” to “C6” blinks.
e Push [
YY
] (or [
ZZ
]) to scroll the message.
• Push [
ZZ
] or [
YY
] to move the cursor to left or right, respectively.
r Push [✱•
ENT
] (or [D•
CLR
])
to exit
OPTION SET MODE
.
